TATP (Mother of Satan) bombs: Lethality, Injuries, Evacuation (Security Measures)
Posted by Arms Control Center in TERRORISM, tags: acetone peroxide, Backpack bomb, bucket bomb, London bomb, London bucket bomb, Mother of Satan, Mother of Satan Bomb, suicide bomber, suitcase bomb, TATP, TATP bomb, TATP bomb in London, triacetone triperoxideSimulation Data: IED using TATP (Triacetone Triperoxide) a.k.a. “Mother of Satan”
(Average scenario for bucket bombs, small suitcase bombs, and suicide bombers)
Density of TATP: 1.2 g/cc
Relative Effectiveness Factor (RE) of TATP=0.8
Quantity of TATP simulated 62.5 lb (equivalent to 50 lb TNT)
The volume of the quantity TATP simulated is 24lt (reasonable volume for bucket bombs, small briefcase bombs, and suicide bombers with an average backpack so as to avoid suspicion etc. This is not the most conservative scenario. This average volume was selected only for purposes of illustration, the Arms Control Center can simulate IED effects of any size and design if necessary.)
Ground Zero: Piccadilly Circus (London)
Software used: First Responder Support Tools (FIRST) and Google Earth Pro
Source of data used in IED simulation: Defense Threat Reduction Agency (DHS)
If the bucket bomb which apparently failed to detonate today in the London underground train had exploded successfully at Piccadilly Circus there would have been many casualties. In this short study, we will simulate such an explosion for educational purposes informing the public and the authorities about the effects.
According to the news an improvised bomb made of TATP (Mother of Satan) was placed in a bucked and left on the floor of an underground carriage in London caused injuries and damages in the London underground train. We don’t know yet whether it was an IED (i.e. an improvised explosive device meant to destroy and kill by its blast wave and shrapnel or if it was an incendiary bomb whose lethal effects are mostly burns and asphyxiation.
The Arms Control Center provides an approximate assessment of the effects such an IED may cause so that the authorities in London can take appropriate measures in case another such a bomb is found. At the same time the emergency personnel, the first responders and the general population will get an idea of the destructive effects of such a device so that they can evacuate the possible ground zero at reasonably large distances without exaggerations and panic which would disrupt the social and economic life of London
Our simulation is valid for bucket bombs, small suitcase bombs, and suicide bombers made of TATP or is equivalent to a 50lb TNT IED
According to a short video which is now all over the internet, the improvised bomb, we don’t call it an improvised explosive device yet, was inside a bucket half covered by a plastic bag apparently used to carry the bomb to ground zero, which was on the floor of an underground carriage. The same video shows that the device is on fire before its explosion while investigators have recovered what appears to be a circuit board from the scene where the device was placed. Apparently the bomb was either attached to a timer or it was meant to explode by remote control. Judging from the damages caused in the carriage and the injuries sustained by the passengers the device must have finally acted more like an incendiary bomb, failing to initiate a detonation, although it is still unclear whether it was an IED that is an improvised explosive device meant to kill by a blast wave and shrapnel or it was actually meant to be an incendiary bomb such as the one found in the Athens Metro in 2012. In any case the Arms Control Center assumes a conservative scenario according to which the device was indeed an IED and that the volume of a sizeable bucket allows for an IED of roughly 50 lb of TNT. We will use this conservative represenation for a bucket bomb to estimate the damage such an IED would have caused had it exploded in the open at the center of the Piccadilly circus. Please note that the damages and injuries caused by a bucket bomb explosion inside the underground carriage would have been much more severe as the walls of the closed carriage would have acted as a tamper enhancing the effects of the blast wave and the shrapnel. Our software, the First Responder Support Tools displays the mandatory evacuation distance and the shelter-in-place distance which are respectively, XXX and XXX feet.
Once detected, a pipe bomb should not be dismantled or even approached as any mistake could trigger an explosion. Since dismantling the pipe bomb is virtually forbidden, the typical method of disarming such a bomb is to destroy it in place or relocate it to a remote area where it can be safely destroyed by experienced bomb disposal personnel. Only authorized law enforcement and bomb disposal personnel should be allowed to approach and handle the explosive device.
Once a bucket bomb is located, all people should assume a safety distance from the bomb until authorized bomb disposal personnel disarms or destroys or relocates the bomb to a safe area. We call that distance, Minimum Evacuation Distance and we define it as the range at which a life-threatening injury from blast or fragmentation hazards is unlikely. However, even at such distances non-life-threatening injuries may occur.
Let’s now define the Minimum Evacuation Distances associated with a bucket bomb modelled in our case as a 50 lb IED.
The US Department of Homeland Security classifies Minimum Evacuation Distances into two major categories
Building Evacuation Distance which for a 50lb IED is 150 feet (roughly 45 meters)
Outdoor Evacuation Distance which for a 50lb IED is 1850 feet (roughly 560 meters)
Builiding Evacuation Distances apply to people who are inside buildings while Outdoor Evacuation Distances apply to people who are outdoors, in the streets or in an open field.
Another interprations of these distances is that a building evacuation distance is actually a mandatory evacuation distance while an outdoors evacuation distance is a shelter-in-place distance.
People inside buildings which shield them from a bucket bomb are provided with a high degree of protection from death or serious injury in case of a bucket bomb explosion; For such people we apply Building Evacuation Distances evacuating them to a distance of 150 feet (roughly 45 meters) away from the bucket bomb. However, glass breakage and building debris may still cause some injuries, therefore whenever a bucket bomb is found in a building it is advisable to evacuate the entire building floor and at least the adjacent ones.
On the other hand, if there are people who are in the vicinity of a bucket bomb and cannot enter a building to seek shelter they should be evacuated to the Outdoor Evacuation Distance, which is 1850 feet (roughly 560 meters) away from the bucket bomb. If evacuation is impossible all people inside the outdoor evacuation distance should at least shelter in place.
As an exercise, we will assume that a bucket bomb explodes at the center of the Piccadilly Circus. We locate on the satellite map the ground zero of the explosion and our software plots two overlapping concentric circular areas centered on ground zero. The yellow circular area has a radius equal to the Outdoor Evacuation Distance that is 1850 feet (roughly 560 meters), while the red circular area which is of a radius of 150 feet (roughly 45 meters) is the mandatory evacuation distance.
At first sight, the Outdoor Evacuation Distance for a 50lb IED defined by the Department of Homeland Security seems unrealistically large. If such a bucket bomb had been found at the Piccadilly Circus, according to the proposed Outdoor Evacuation Distances many London City blocks should have been evacuated, causing unnecessarily many exaggerated financial and psychological impacts. Although the much more realistic 100-meter red color Evacuation area would suffice for bucket bombs, our Arms Control Center, advises that the DHS standards should be applied in all cases, if possible.
To further analyze the effects of a bucket bomb, modelled in our case as a 50lb IED, we apply our software to estimate additional risk zones.
For example the turquoise circular zone which has a radius of 250 feet (roughly 76 meters) indicates the threshold for minor glass cuts meaning that people outside that zone are not expected to sustain any risks from glass fracture, let alone from the blast wave or other bomb effects.
On the other hand the pink circular which has a radius of 105 feet (roughly 32 meters) indicates the threshold for mild injuries due to blast and fragments.
Finally the inner zone which has a radius of 70 feet (roughly 21 meters) represents the lethality threshold so that all people inside that central zone may sustain lethal injuries.
